Calcium Sulphate Carpet Raised Flooring

Calcium Sulphate Carpet Panel is manufactured from 1600 Kg/ cubic meter density fiber reinforced Calcium Sulphate which forms the core of the panel. Non- combustible high-quality alpha- hemihydrate single pressed gypsum and non-toxic unbleached cellulose fibers are used as reinforcing the material. The base & top surface of the core is factory bonded using an appropriate combination of surface finishes such as Aluminum, Galvanized sheet steel, High-Pressure Laminate, etc. The edges of the panel are protected with a PVC edge band. The system offers an excellent acoustical sound deadening value.

Panel Specifications

Panel Class: Calcium Sulphate Carpet Raised Floor Panel Type : CS6 / H40 Panel Dimensions: 600 x 600 mm Panel Thickness: ~ 40 mm Top Covering: HPL Bottom Covering: Aluminum sheet Edge: ABS edge band Panel Weight : ~ 8,50 kg/panel System Weight: ~ 25,35 kg/m2 (For height 15-20 cm) Panel Core: 30 mm high-density chipboard Fire Reaction: Bfl-s1

Panel Load Values (according to EN 12825)

Working Load: 1,5 kN

Maximum Load: > 4,00 kN

Safety Factor: 3

Panel Load Deflection Class: 1B
